Description

Dimensions
Article Diameter (in mm) 1320
Article Height (in mm) 318
Canopy Height (in mm) 56
Canopy Diameter (in mm) 142
Net Weight (in kg) 6.1 Kilogram
Gross Weight 7.1 Kilogram
Single-Box Height (in mm) 264
Single-Box Length (in mm) 611
Single-Box Depth (in mm) 251

Fan
Motor Type DC
Motor dimension in MM (Ø x H) 155mm
Motor Wattage 28
Blade pitch in degree 11
Blade Quantity 4
Mains Voltage 220-240V, 50Hz

Material & Colour
Blade Material ABS, UV Resistant
Blade Colour (1) white matt
Canopy Material steel
Canopy Colour white matt
Enclosure Material steel
Enclosure Colour white matt

Performance
Wattage by air movement (1) 1.9
RPM (1) 65
Air Movement m3/Hr (1) 2625
Wattage by air movement (2) 3
RPM (2) 95
Air Movement m3/Hr (2) 4500
Wattage by air movement (3) 5.2
RPM (3) 125
Air Movement m3/Hr (3) 5815
Wattage by air movement (4) 8.7
RPM (4) 155
Air Movement m3/Hr (4) 7880
Wattage by air movement (5) 14.8
RPM (5) 185
Air Movement m3/Hr (5) 9110
Wattage by air movement (6) 25.7
RPM (6) 220
Air Movement m3/Hr (6) 10820

Remote Controls for AC and DC Ceiling Fans :
As per Wiring Regulation, an Isolator Switch must be installed for each Remote Controlled Ceiling Fans which is to be purchased separately. This does not apply to Wall Switch controlled Ceiling Fans
