Description

Dimensions
Article Diameter (in mm) 2032
Article Height (in mm) 413
Canopy Height (in mm) 54
Canopy Diameter (in mm) 150
Net Weight (in kg) 14.4 Kilogram
Gross Weight 16.5 Kilogram
Single-Box Height (in mm) 259
Single-Box Length (in mm) 980
Single-Box Depth (in mm) 402

Fan
Motor Type DC
Motor dimension in MM (Ø x H) 180×17
Motor Wattage 58
Blade pitch in degree 18°
Blade Quantity 7
Mains Voltage 220-240V, 50Hz

Material & Colour
Blade Material aluminium
Blade Colour (1) white matt
Canopy Material steel
Canopy Colour white matt
Enclosure Material steel
Enclosure Colour white matt

Performance
Wattage by air movement (1) 15.5
RPM (1) 53
Air Movement m3/Hr (1) 5440
Wattage by air movement (2) 22
RPM (2) 74
Air Movement m3/Hr (2) 10370
Wattage by air movement (3) 34
RPM (3) 84
Air Movement m3/Hr (3) 11950
Wattage by air movement (4) 48
RPM (4) 92
Air Movement m3/Hr (4) 15470
Wattage by air movement (5) 58
RPM (5) 100
Air Movement m3/Hr (5) 17500

Remote Controls for AC and DC Ceiling Fans :
As per Wiring Regulation, an Isolator Switch must be installed for each Remote Controlled Ceiling Fans which is to be purchased separately. This does not apply to Wall Switch controlled Ceiling Fans
